Final Exam

For the Ozone data from the R package mlbench try the following machine learning prediction algorithm. Read the paper Feature Selection with the Boruta Package and implement the algorithm. Build prediction model for the Ozone variable. Which features are most important?

  • 1. Boruta RandomForest Algorithm

NAME: SAJITH GOWTHAMAN NET ID: ek5282

In [1]:
import pandas as pd
import numpy as np
import matplotlib.pyplot as plt
import seaborn as sns
%matplotlib inline
import matplotlib.pyplot as plt
%matplotlib inline
In [2]:
df = pd.read_csv("Ozone.csv")
In [3]:
df.head()
Out[3]:
Unnamed: 0 V1 V2 V3 V4 V5 V6 V7 V8 V9 V10 V11 V12 V13
0 1 1 1 4 3.0 5480.0 8 20.0 NaN NaN 5000.0 -15.0 30.56 200
1 2 1 2 5 3.0 5660.0 6 NaN 38.0 NaN NaN -14.0 NaN 300
2 3 1 3 6 3.0 5710.0 4 28.0 40.0 NaN 2693.0 -25.0 47.66 250
3 4 1 4 7 5.0 5700.0 3 37.0 45.0 NaN 590.0 -24.0 55.04 100
4 5 1 5 1 5.0 5760.0 3 51.0 54.0 45.32 1450.0 25.0 57.02 60
In [4]:
df.isna().sum()
Out[4]:
Unnamed: 0      0
V1              0
V2              0
V3              0
V4              5
V5             12
V6              0
V7             15
V8              2
V9            139
V10            15
V11             1
V12            14
V13             0
dtype: int64

We find a lot of NaN values associated with the data. For a prediction model, it is advised to take the mean of the values of it's respective columns. As this particular data deals with the temperature, we shouldn't expect sudden ups and downs of the values. Mean value would be suitable.

In [5]:
df.mean()
Out[5]:
Unnamed: 0     183.500000
V1               6.513661
V2              15.756831
V3               4.002732
V4              11.526316
V5            5752.966102
V6               4.868852
V7              58.475783
V8              61.914835
V9              56.846344
V10           2590.943020
V11             17.797260
V12             60.927330
V13            123.300546
dtype: float64
In [6]:
df.fillna(df.mean(), inplace = True)

Let's check the predicting target's data, whether we can do a classification or regression model.

In [7]:
df.info()
df.describe()
<class 'pandas.core.frame.DataFrame'>
RangeIndex: 366 entries, 0 to 365
Data columns (total 14 columns):
Unnamed: 0    366 non-null int64
V1            366 non-null int64
V2            366 non-null int64
V3            366 non-null int64
V4            366 non-null float64
V5            366 non-null float64
V6            366 non-null int64
V7            366 non-null float64
V8            366 non-null float64
V9            366 non-null float64
V10           366 non-null float64
V11           366 non-null float64
V12           366 non-null float64
V13           366 non-null int64
dtypes: float64(8), int64(6)
memory usage: 40.2 KB
Out[7]:
Unnamed: 0 V1 V2 V3 V4 V5 V6 V7 V8 V9 V10 V11 V12 V13
count 366.000000 366.000000 366.000000 366.000000 366.000000 366.000000 366.000000 366.000000 366.000000 366.000000 366.000000 366.000000 366.000000 366.000000
mean 183.500000 6.513661 15.756831 4.002732 11.526316 5752.966102 4.868852 58.475783 61.914835 56.846344 2590.943020 17.797260 60.927330 123.300546
std 105.799338 3.455958 8.823592 1.997942 7.861472 103.253719 2.116928 19.348962 14.237358 9.173890 1759.520751 36.061021 13.602462 80.280142
min 1.000000 1.000000 1.000000 1.000000 1.000000 5320.000000 0.000000 19.000000 25.000000 27.680000 111.000000 -69.000000 27.500000 0.000000
25% 92.250000 4.000000 8.000000 2.000000 5.000000 5700.000000 3.000000 50.000000 51.250000 54.320000 899.000000 -9.750000 51.620000 70.000000
50% 183.500000 7.000000 16.000000 4.000000 10.000000 5760.000000 5.000000 64.000000 62.000000 56.846344 2380.000000 24.000000 61.160000 110.000000
75% 274.750000 9.750000 23.000000 6.000000 16.000000 5830.000000 6.000000 73.000000 72.000000 59.990000 5000.000000 45.000000 70.340000 150.000000
max 366.000000 12.000000 31.000000 7.000000 38.000000 5950.000000 11.000000 93.000000 93.000000 82.580000 5000.000000 107.000000 91.760000 500.000000
In [8]:
sns.pairplot(df)
Out[8]:
<seaborn.axisgrid.PairGrid at 0x12b684d10>
In [9]:
df.V4 = round(df.V4)
df.V4 = pd.to_numeric(df['V4'])
In [10]:
df.V4.unique()
Out[10]:
array([ 3.,  5.,  6.,  4.,  7.,  9., 11., 10., 12.,  2.,  8., 13., 15.,
       23., 17., 16., 24., 14., 22., 19., 18., 21., 29., 20., 27., 33.,
       25., 31., 26., 30., 28., 34., 32., 38.,  1.])
In [11]:
##Let's Load X and Y

X=df.loc[:, df.columns != 'V4'].values
Y=df.iloc[:,4].values.ravel()

Boruta Model (with Random Forest):

In [12]:
from sklearn.ensemble import RandomForestClassifier
from boruta import BorutaPy
rf = RandomForestClassifier(n_jobs=-1, class_weight=None, max_depth=2)

# define Boruta feature selection method
feat_selector = BorutaPy(rf, n_estimators='auto', verbose=2, max_iter = 30)

# find all relevant features
feat_selector.fit(X, Y)

# check ranking of features
feat_selector.ranking_
Iteration: 	1 / 30
Confirmed: 	0
Tentative: 	13
Rejected: 	0
Iteration: 	2 / 30
Confirmed: 	0
Tentative: 	13
Rejected: 	0
Iteration: 	3 / 30
Confirmed: 	0
Tentative: 	13
Rejected: 	0
Iteration: 	4 / 30
Confirmed: 	0
Tentative: 	13
Rejected: 	0
Iteration: 	5 / 30
Confirmed: 	0
Tentative: 	13
Rejected: 	0
Iteration: 	6 / 30
Confirmed: 	0
Tentative: 	13
Rejected: 	0
Iteration: 	7 / 30
Confirmed: 	0
Tentative: 	13
Rejected: 	0
Iteration: 	8 / 30
Confirmed: 	7
Tentative: 	4
Rejected: 	2
Iteration: 	9 / 30
Confirmed: 	7
Tentative: 	4
Rejected: 	2
Iteration: 	10 / 30
Confirmed: 	7
Tentative: 	4
Rejected: 	2
Iteration: 	11 / 30
Confirmed: 	7
Tentative: 	4
Rejected: 	2
Iteration: 	12 / 30
Confirmed: 	7
Tentative: 	4
Rejected: 	2
Iteration: 	13 / 30
Confirmed: 	7
Tentative: 	4
Rejected: 	2
Iteration: 	14 / 30
Confirmed: 	7
Tentative: 	4
Rejected: 	2
Iteration: 	15 / 30
Confirmed: 	7
Tentative: 	4
Rejected: 	2
Iteration: 	16 / 30
Confirmed: 	9
Tentative: 	2
Rejected: 	2
Iteration: 	17 / 30
Confirmed: 	9
Tentative: 	2
Rejected: 	2
Iteration: 	18 / 30
Confirmed: 	9
Tentative: 	2
Rejected: 	2
Iteration: 	19 / 30
Confirmed: 	9
Tentative: 	2
Rejected: 	2
Iteration: 	20 / 30
Confirmed: 	9
Tentative: 	2
Rejected: 	2
Iteration: 	21 / 30
Confirmed: 	9
Tentative: 	2
Rejected: 	2
Iteration: 	22 / 30
Confirmed: 	9
Tentative: 	1
Rejected: 	3
Iteration: 	23 / 30
Confirmed: 	9
Tentative: 	1
Rejected: 	3
Iteration: 	24 / 30
Confirmed: 	9
Tentative: 	1
Rejected: 	3
Iteration: 	25 / 30
Confirmed: 	9
Tentative: 	1
Rejected: 	3
Iteration: 	26 / 30
Confirmed: 	10
Tentative: 	0
Rejected: 	3


BorutaPy finished running.

Iteration: 	27 / 30
Confirmed: 	10
Tentative: 	0
Rejected: 	3
Out[12]:
array([1, 1, 2, 4, 1, 3, 1, 1, 1, 1, 1, 1, 1])
In [13]:
feat_selector.support_
Out[13]:
array([ True,  True, False, False,  True, False,  True,  True,  True,
        True,  True,  True,  True])
In [14]:
print('==============BORUTA==============')
print (feat_selector.n_features_)
==============BORUTA==============
10

I was first getting the top 4 important features. After some tuning I was able to get the all the important features. (Same when I ran with R-Studio)

In [15]:
features = [f for f in df.columns if f not in ['V4']]
len(features)
Out[15]:
13
In [16]:
important_features = list()
indexes = np.where(feat_selector.support_ == True)
for x in np.nditer(indexes):
    important_features.append(features[x])
print('The Most Important Features Are:{}'.format(important_features))

unimportant_features = list()
indexes = np.where(feat_selector.support_ == False)
for x in np.nditer(indexes):
    unimportant_features.append(features[x])
print('The Unimportant Features Are:{}'.format(unimportant_features))
The Most Important Features Are:['Unnamed: 0', 'V1', 'V5', 'V7', 'V8', 'V9', 'V10', 'V11', 'V12', 'V13']
The Unimportant Features Are:['V2', 'V3', 'V6']

Dataset before filtering to the transformed version:

In [17]:
imp_df = pd.DataFrame(df[important_features])
imp_df
Out[17]:
Unnamed: 0 V1 V5 V7 V8 V9 V10 V11 V12 V13
0 1 1 5480.000000 20.000000 61.914835 56.846344 5000.00000 -15.0 30.56000 200
1 2 1 5660.000000 58.475783 38.000000 56.846344 2590.94302 -14.0 60.92733 300
2 3 1 5710.000000 28.000000 40.000000 56.846344 2693.00000 -25.0 47.66000 250
3 4 1 5700.000000 37.000000 45.000000 56.846344 590.00000 -24.0 55.04000 100
4 5 1 5760.000000 51.000000 54.000000 45.320000 1450.00000 25.0 57.02000 60
... ... ... ... ... ... ... ... ... ... ...
361 362 12 5730.000000 53.000000 51.000000 49.280000 111.00000 -14.0 72.50000 200
362 363 12 5690.000000 23.000000 51.000000 49.280000 5000.00000 -36.0 51.26000 70
363 364 12 5650.000000 61.000000 50.000000 46.580000 3704.00000 18.0 46.94000 40
364 365 12 5550.000000 85.000000 39.000000 41.000000 5000.00000 8.0 39.92000 100
365 366 12 5752.966102 68.000000 37.000000 56.846344 5000.00000 -3.0 37.22000 70

366 rows × 10 columns

The most important features were found to be 'Unnamed: 0', 'V1', 'V5', 'V7', 'V8', 'V9', 'V10', 'V11', 'V12' and 'V13'

In [18]:
#call transform() on X to filter it down to selected features
X_filtered = feat_selector.transform(X)
X_filtered.shape
Out[18]:
(366, 10)
In [19]:
X_filtered_df = pd.DataFrame(X_filtered)

Dataset after transofrming to the selected features

Perfect, it looks exactly like the expected results! (compared to the one before transforming)

In [20]:
X_filtered_df
Out[20]:
0 1 2 3 4 5 6 7 8 9
0 1.0 1.0 5480.000000 20.000000 61.914835 56.846344 5000.00000 -15.0 30.56000 200.0
1 2.0 1.0 5660.000000 58.475783 38.000000 56.846344 2590.94302 -14.0 60.92733 300.0
2 3.0 1.0 5710.000000 28.000000 40.000000 56.846344 2693.00000 -25.0 47.66000 250.0
3 4.0 1.0 5700.000000 37.000000 45.000000 56.846344 590.00000 -24.0 55.04000 100.0
4 5.0 1.0 5760.000000 51.000000 54.000000 45.320000 1450.00000 25.0 57.02000 60.0
... ... ... ... ... ... ... ... ... ... ...
361 362.0 12.0 5730.000000 53.000000 51.000000 49.280000 111.00000 -14.0 72.50000 200.0
362 363.0 12.0 5690.000000 23.000000 51.000000 49.280000 5000.00000 -36.0 51.26000 70.0
363 364.0 12.0 5650.000000 61.000000 50.000000 46.580000 3704.00000 18.0 46.94000 40.0
364 365.0 12.0 5550.000000 85.000000 39.000000 41.000000 5000.00000 8.0 39.92000 100.0
365 366.0 12.0 5752.966102 68.000000 37.000000 56.846344 5000.00000 -3.0 37.22000 70.0

366 rows × 10 columns

Let's check how the boruta model has changed the distribution of the 10 variables with HvPlot

In [21]:
import hvplot.pandas
import holoviews as hv

(X_filtered_df.hvplot(kind='scatter', x='0', y='1', by='0') + X_filtered_df.hvplot(kind='scatter', x='0', y='1', by='1') + X_filtered_df.hvplot(kind='scatter', x='0', y='1', by='1'))
Out[21]:
In [24]:
from sklearn.model_selection import train_test_split
from sklearn.ensemble import RandomForestClassifier
from sklearn.metrics import classification_report
from sklearn import ensemble

X = imp_df
Y= df.V4
In [25]:
df_rf_clf = ensemble.RandomForestClassifier(n_estimators=23)
df_rf_clf.fit(X,Y)
Out[25]:
RandomForestClassifier(bootstrap=True, class_weight=None, criterion='gini',
                       max_depth=None, max_features='auto', max_leaf_nodes=None,
                       min_impurity_decrease=0.0, min_impurity_split=None,
                       min_samples_leaf=1, min_samples_split=2,
                       min_weight_fraction_leaf=0.0, n_estimators=23,
                       n_jobs=None, oob_score=False, random_state=None,
                       verbose=0, warm_start=False)
In [26]:
predictions = df_rf_clf.predict(X)

Predictions For "Ozone" Variable:

In [28]:
predictions
Out[28]:
array([ 3.,  3.,  3.,  5.,  5.,  6.,  4.,  4.,  6.,  7.,  4.,  6.,  5.,
        4.,  4.,  7.,  5.,  9.,  4.,  3.,  4.,  4.,  5.,  6.,  9.,  5.,
        6.,  6.,  6., 11., 10.,  7., 12.,  9.,  2.,  3.,  3.,  2.,  3.,
        3.,  4.,  6.,  8.,  6.,  4.,  3.,  7., 11., 13.,  4.,  6.,  5.,
        4.,  4.,  6., 10., 15., 23., 17.,  7.,  2.,  3.,  3.,  5.,  4.,
        6.,  7.,  7.,  6.,  3.,  2.,  8., 12., 12., 16.,  9., 24., 13.,
        8., 10.,  8.,  9., 10., 13., 14.,  9., 11.,  7.,  9., 12., 12.,
        8.,  9.,  5.,  4.,  4.,  9., 13.,  5., 10., 10.,  7.,  5.,  4.,
        7.,  3.,  3.,  7., 11., 15., 22., 17.,  7., 10., 19., 18., 12.,
        6.,  9., 19., 21., 29., 16.,  5., 11.,  2.,  2., 12., 16., 22.,
       20., 27., 33., 25., 31., 18., 16., 24., 16., 12.,  9., 12., 16.,
       12.,  8.,  9., 29., 20.,  5.,  5., 11., 12., 19., 17., 19., 16.,
       14., 10.,  9.,  7.,  5.,  2., 12., 22., 17., 26., 27., 14., 11.,
       23., 26., 21., 15., 20., 15., 18., 26., 19., 13., 30., 26., 15.,
       16., 16., 19., 23., 28., 34., 33., 12., 24., 17., 10., 14., 13.,
       17., 15., 22., 19., 20., 25., 28., 29., 12., 23., 26., 14., 13.,
       26., 22., 11., 15., 14., 13.,  9., 12., 15., 12., 15., 25., 18.,
       14., 22., 24., 19., 16.,  7.,  2.,  4.,  6., 12.,  9., 15., 17.,
       13., 20., 22., 24., 26., 32., 33., 27., 38., 23., 19., 19., 15.,
       28., 10., 14., 26., 17.,  3.,  2.,  3., 14., 29., 18.,  3.,  7.,
        9., 19.,  8., 12., 23., 13., 12.,  7.,  3.,  5., 11., 12.,  5.,
        4.,  5.,  4., 10., 17., 26., 30., 18., 12.,  7., 15., 12.,  7.,
       28., 22., 18., 14., 24., 10., 14.,  9., 12.,  7.,  7.,  6., 13.,
        5.,  3.,  7.,  8., 10., 12.,  7.,  5.,  6.,  4.,  5., 11., 20.,
        4., 14., 16.,  5.,  3.,  5.,  1.,  5.,  4., 11.,  6.,  8., 14.,
       18., 12.,  9.,  7., 14.,  4.,  3.,  3.,  3.,  3.,  3.,  3.,  3.,
        6.,  6.,  5.,  3.,  4.,  7.,  5.,  5.,  4.,  3.,  2.,  5.,  3.,
        4.,  4.,  6.,  6.,  3.,  4.,  3.,  8.,  5.,  3.,  2.,  3.,  5.,
        1.,  2.])
In [ ]:
